Small Venue Presentation Switcher with 4K Capabilities

Awesome Features

  • 4K
  • Multi-Output
  • HDR

The PDS 4K is an extremely versatile small screen switcher with layering, multiviewer, and capable of up to 4x4k@30 outputs.
Small Venue, Breakouts
Small Venue Presentation Switcher with 4K Capabilities

Manufacture Notes

The PDS series is designed to meet today’s requirements for a high-quality, easy-to-use and fast seamless switcher with more digital inputs at an affordable price. It is the perfect fit for mid-sized live events, breakout sessions, seminar rooms and boardrooms.

The PDS-4K SDI enables single screen, dual screen switching and quad screen switching with high-quality 4K processing, and it can also support Dante® audio with the addition of an optional interface card. It includes six HDMI 2.0 and two 12G-SDI inputs and four fully seamless mixing program outputs at up to 4K resolution on HDMI 2.0 and 12G-SDI connectors. Benefit from the ultra-low latency processing (≤ 2 frames delay @60Hz), smooth video display and seamless transitions between inputs to maximize audience engagement. Additionally, you can increase interactivity by showing up to two live inputs simultaneously with the available PiP layers. And the Event Master AthenaTM scaling technology guarantees superior signal clarity and minimum scaling artifacts.

Why this Solution

Tech Specs

  • Inputs:
    6x HDMI 2.0, 2x 12G SDI
  • Outputs:
    4x HDMI 2.0, 4x 12G SDI, HDMI 2.0/12G GUI
  • GPU:
    1 Mixing Layer Per PGM Out
  • Dimensions:
    2RU 484.1 x 409 x 66.2 mm
  • Power:
  • Accessories:
    Dante Audio Card


Solutionist Approved

Let’s Talk About the PDS-4K SDI
